3nh colorimeter spectrophotometer is widely used in plastic, electronic, paint, ink, textile, garment, printing and dyeing, food, medical, cosmetic industries, scientific research institutes, schools and laboratories. It not only can help to perform color matching and color management studies, but also can control product quality management. 3nh colorimeter is equipped with high-end color management software that can connect to PC to achieve more extension functions.

1. 8mm and 4mm double aperture for switch, easy to measure concave sample in large plane
2. More stable and accurate, ΔE*ab<0.03
3. Many color spaces, many color indexes, extensive applicability
4. Double locating: illuminating locating and cross locating
5. Equipped with rechargeable high-capacity li-ion battery
6. Built-in white plate parameters, and configuration of physical whiteboard, easy to operate
7. New integrating sphere optical path design, more stable to measure
8. Double aperture measurement data can pass SCM metrological certification

• Illuminating/Viewing Geometry: 8*/d
• Light Source: LED light
• Sensor: silicon photodiode array
• Measuring Aperture: Φ8mm flat aperture; Φ8mm tip aperture
• Color Space: CIE LAB, XYZ, LCH, CIE RGB, CIE LUV
• Color Difference Formula: ΔE* ab, ΔE(h), ΔE* uv, ΔE* 94, ΔE* cmc(2:1), ΔE* cmc(1:1), ΔE* 00
• Other Chromaticity Data: WI, Color Fastness, Staining Fastness, J PC79, BFD(1, 5:1), FMCI I
• Observer: CI E 10*
• Illuminant: D65, A, C, D50, F2, F6, F7, F8, F10, F11, F12
• Display Data: Colorimeter Value, Color Difference Value/Graph, PASS/FAIL Result, Color offset
• Measurement Time: 0.4s
• Repeatability: ΔE* ab 0.03 (Average of 30 measurements of standard white plate within 5s
• Errors Between Each Instrument: Within Delta E* ab 0.2
• Dimension: 205*67*80mm
• Weight: 500g
• Battery: rechargeable Lithium-ion battery 3.7V @3200 mAh
• Lamp Life: 5 years, more than 1.6 million measurements
• Screen: TFT2.8 inch (16:9)
• Interface: USB/RS-232
• Storage: 100 standards, 20000 samples
• Operating Temperature: 0~40°C (32~104°F)
• Storage Temperature: -20~50°C (-4~122°F)
• PC Software: CQCS3 software
• Optional Accessory: miniature thermal printer, powder test box
